What is it 8-Position Adjustable Trailer Hitch Ball Mount
This is 8-position adjustable trailer hitch ball mount built for 2-inch receivers. It comes with a 2-inch hitch ball and a 5/8" pin lock, offering 7,500 lbs GTW capacity. The mount provides 9-1/2" maximum drop and 8-1/4" maximum rise, allowing users to select the right height for level towing. The black powder coated body and chrome-plated ball deliver strength and durability for daily towing.
8-Position Adjustable Trailer Hitch Ball Mount Specifications Table
| Item | Specification |
| Product Name | Adjustable Trailer Hitch Ball Mount |
| Receiver Size | 2-inch receiver |
| Ball Size | 2-inch |
| Pin Lock | 5/8" pin lock |
| Max GTW | 7,500 lbs |
| Drop | 9-1/2" |
| Rise | 8-1/4" |
| Adjustment Positions | 8 positions |
| Material | High-strength steel |
| Surface Treatment | Black powder coated |
| Ball | Forged steel, chrome plated |
| Package | Inner box + export carton + pallet |
| Warranty | 12 months |
| Custom Service | Laser marking logo, OEM & ODM available |
8-Position Adjustable Trailer Hitch Ball Mount Feature
1. 8-position adjustment
Eight height positions let users fine-tune the ball height for different truck and trailer setups.
2. 9-1/2" drop & 8-1/4" rise
Wide adjustment range helps achieve level towing, improving stability and reducing rear sag.
3. 2-inch receiver compatible
Designed for standard 2-inch square receivers on most pickup trucks.
4. 2-inch ball included
Fits common 2-inch trailer couplers for everyday towing applications.
5. 5/8" pin lock
Heavy-duty pin and lock system helps secure the adjustable bracket and improve towing safety.
6. 7,500 lbs capacity
Reliable load rating for light to medium-heavy trailer towing.
7. Durable steel construction
High-strength steel with black powder coating resists wear and corrosion in outdoor use.
8. Chrome-plated ball
Hard, smooth surface provides long life and easy coupling.
8-Position Adjustable Trailer Hitch Ball Mount Application
· Pickup trucks with 2-inch receivers
· Utility trailers
· Boat trailers
· RVs and campers
· Flatbed trailers
· Daily recreational and light commercial towing
8-Position Adjustable Trailer Hitch Ball Mount FAQ
Q1: What receiver does this fit?
A: It fits standard 2-inch square receivers.
Q2: What ball size is included?
A: It includes a 2-inch hitch ball.
Q3: How many adjustment positions are there?
A: There are 8 adjustable height positions.
Q4: What is the maximum drop and rise?
A: Maximum drop is 9-1/2" and maximum rise is 8-1/4".
Q5: What is the load capacity?
A: The rated capacity is 7,500 lbs GTW. Do not exceed the lowest rated component in your towing system.
Q6: Does it include a pin lock?
A: Yes, it comes with a 5/8" pin lock.
Q7: Is it durable?
A: Yes, it is made of high-strength steel with black powder coating and a chrome-plated ball.
Q8: Can you add our logo?
A: Yes, laser marking logo is available for bulk orders.
